The Ultralux® LED emergency lighting fixture has a built-in Ni-Cd battery that provides at least 2 hours lighting, after the power fails. If the supply voltage is present, the battery charges. When the power fails, the fixture will go into emergency mode, powered by the built-in Ni-Cd battery.
When the supply voltage is on (normal mode), the light can be switched on / off by an external switch.
| Snaga | 3W |
| Napon AC | 220-240V |
| Frekvencija | 50-60Hz |
| Razred | II |
| Svjetlosni tok | 50lm |
| Temperatura boje (CCT) | 6500K |
| Indeks prikaza boja (CRI) | >70 |
| Raspodjela svjetlosti | ⁰ |
| svjetlosni tok u slučaju nužde | 140lm |
| Stupanj zaštite | IP44 |
| Dimenzije | 346/107/60mm |
| Vrijeme svijetljenja | 120min |
| Baterija | Ni-Cd 1500 mAh/ 3.6V |
| Jamstvo | 2 godine |
| Vrijeme punjenja | 20h |
The Ultralux® LED emergency lighting fixture has a built-in Ni-Cd battery that provides at least 2 hours lighting, after the power fails. If the supply voltage is present, the battery charges. When the power fails, the fixture will go into emergency mode, powered by the built-in Ni-Cd battery.
When the supply voltage is on (normal mode), the light can be switched on / off by an external switch.
